PROPOSAL OF TOOTHBRUSH MAKING PLANT

Example¡G

X area has a population of 10,000,000, in which everyone must use 4 toothbrushes per year , and three toothbrush making plants have been found here. So what proposal will the forth new-establishing toothbrush making plant need to have if it expects 10% of annual output amongest 40,000,000 pcs of T/brushes ¡X 40,000,000pcs ¡Ñ 10% ¡Ò250 days/year= 16,000 pcs?(42 holes 8 hrs. daily basis)
¡@
1. PLAN LAYOUT(10M¡Ñ25M)
¡@
2. MACHINERY & EQUIPMENTS REQUIRE
Description Quantity Capacity Man power required Motor Kilowatts Voltage Hertz
Injection Moulding Machie & Related Equipmen 2 Unit
 1 injecting impression/40 sec.,700~800 impressions/8hrs.daily 8hrs.¡Ñ60min. ¡Ñ60sec.¡Ò40sec. ¡Ñ8pcs¡Ñ2=115250pcs
 (Workers)
1~2		 15HP¡Ñ2(4.5OZ) 10KW¡Ñ2 Three Phase
220v		 50HZ or 60HZ
OWN'S-10
8 Cavities Handle Mould		 2 Moulds  ¡@ ¡@ ¡@ ¡@
OWN'S-42
Automatic Material Bristle Cutter & Water Separator M/C		 1Unit
 Having material bristle cut for 1 hr. per day ¡@ 1/2HP¡Ñ2 0.375KW¡Ñ1 Single Phase
220v		 50HZ~60HZ
OWN'S-100
Automatic 2-Colour Toothbrush Tufting M/C 		6 Units 250 tufts/min. ¡Ò42 holes¡Ñ60min. ¡Ñ7hrs. ¡Ñ6units¡Ü15000pcs (Workers)
2		 1/4HP¡Ñ6 0.19KW¡Ñ6 Single Phase
220v		 50HZ~60HZ
Own's-60
Auto Bristle Trimming and End-rounding M/C
(Flat type)		 1 Unit
(¥x)		 3600pcs/hr. ¡Ñ8hrs.¡Ü28800pcs (worker)
1		 2HP¡Ñ2 1.5KW¡Ñ1 Single Phase
 220v		 50HZ~60HZ
Own's-71
Semi-Auto Bristle Trimming M/C(Waved type, etc)		 1 Unit 1200pcs/hr. ¡Ñ8hrs.=9600pcs (worker)
1		 1/3HP¡Ñ2 0.25KW¡Ñ1 Single Phase
220v		 50HZ~60HZ
Own's-30
Air-pressure Hot Stamping M/C		 1 Unit 1500pcs/hr.hr¡Ñ8hrs.=12000pcs (worker)
1		 1HP¡Ñ2 0.75KW¡Ñ1 Single Phase 220v 50HZ~60HZ
Packing Machine & Related Equipments It depends on what types of packing will be picked up. (Workers)
8~10¤H		 ¡@ ¡@ ¡@ ¡@
Air Compressor 1 Unit ¡@ ¡@ 2HP for InjectionMoulding M/C& Air-pressureHot Stamping M/C3 HP for T/brushMaking M/cs 3.75KW¡Ñ1 Three Phase
220v		 50HZ or 60HZ
3. RAM MATERIAL REQUIRED
¡@ Raw Material of Handle
(PP CA or ABS)		 Material Bristle
(Nylon-612)		 Flat Brass Wire
Capacity
 120pcs 654pcs 4760pcs
1kg(PP) 1kg 1kg
Consumption/8hrs. daily 16000pcs¡Ò120pcs¡Ü133kgs
(PP)		 16000pcs¡Ò654pcs¡Ü24.5kgs
 16000pcs¡Ò4760pcs¡Ü3.4kgs
¡@
If you want to get the correct detailed production information, please send 2pcs of each samples of your required production toothbrush and tell us about your required production capacity of each sample per 8 hours, then we will evaluate and offer you the correct detailed information of required machinery.

                                     TEL : 886-2-29891101   FAX : 886-2-29837666
                                              E-mail : wanhsintoothbrush@gmail.com
